Automatic flip-over double-sided deburring machine (vacuum adsorption type)-Vantrn Al-Machienry

Parameters Principle Diagram Applications Video

Main Function Features

1. The whole line is completed in turn with automatic loading, double-sided precision polishing and deburring, cleaning and drying to prevent rust. Automatic receiving and all other processes. Each minute can process 60--100 pieces of various valve plates, friction plates, thrusters, spacers and other workpieces; assembly line through the operation, modular combination, customers according to the needs of the whole purchase or optional related modules.

2. The whole set of equipment is the world's first automatic double-sided polishing, cleaning and drying production line special equipment, Wanchuang has completely independent intellectual property rights, the whole authorized invention patents and software copyright certification;

3. The excellent structure and function of the equipment ensure the super durability, safety and stability of the equipment; the equipment is energy efficient, convenient in operation and simple in maintenance, and the technical functions are far ahead of similar equipment at home and abroad.

The equipment is developed and manufactured by Wanchuang independently, and Wanchuang has completely independent intellectual property rights, the whole machine has been authorized to patent, and imitation is prohibited.

Product Parameters

Scope of Application: Suitable for processing metal products of 40*100mm in length and width or diameter, finishing the polishing and deburring process of front and back side of the parts in one time;

Equipment Configuration: Front side polishing (single or multi-station brush disc combination) + automatic flip side conveying + back side polishing (single or multi-station brush disc combination), can be connected with cleaning and drying, increase automatic feeding and receiving mechanism shape or production line;

Grinding Method: Vacuum adsorption dry grinding. Equipped with vacuum dust collection;

Control System: Man-machine interface control, -key to start the whole set of equipment operation; 5) size: total length about 4.5-6M * width 1.2m * height 2.2m; 6) total power: 15-25KW.
